Stanley Box Scraper - No. 70

stanley scraper 70
Our Rating
User Rating

The Verdict

Stanley 70 Review By: I.Ball


Manufacturer: Stanley

Plane Type: Box Scraper

Model No: 70

The Stanley box scraper number 70 consists of a small hinged head equipped with a 51mm (2 inch) wide scraper blade which is all controlled with a long hardwood handle.

The base on the Stanley 70 scraper is slightly convex; the 70 scraper blade mirror's this curvature.

The head has the Stanley black japanned finish.

Over the years there has been a few different design modifications, mainly to the material used. The hardwood handle has been made using Maple with a brass ferrule, with later examples having a steel ferrule and a hardwood handle with a lacquered finish.



old stanley 70 scraper

The tool as the name suggests is ideal for scraping small work such as boxes.

In particular the box scraper is ideal for removing marks such as pencil marks and removing any knotty unevenness.

The oldest Stanley 70 scrapers were made by Stanley Rule & Level. If the original blade is still present it will have the markings 'Stanley Rule & Level' across it.


1.

Scraper Construction

stanley 70 scraper

Body:
high grade cast iron

Lever cap:
high grade cast iron

Scraper Blade:
best steel

Handle:
maple

Ferrule:
brass

Plane finish:
black

Overall Length: 13 inch

Scraper Blade Width: 51mm (2 inch)

Date: <1898 - 1934>


2.

Scraper Construction

stanley 70 scraper

Body:
high grade cast iron

Lever cap:
high grade cast iron

Scraper Blade:
best steel

Handle:
selected hardwood with lacquered finish / grey hardwood

Ferrule:
steel

Plane finish:
black

Overall Length: 13 inch

Scraper Blade Width: 51mm (2 inch)

Date: 1935> - 1958


3.

Manufactured Dates

<1898 - 1958

4.
